XC3000 Water Cooling Gantry Fiber Laser Cutting Machine New for Raytools for Grille Door Window Advertising for Sheet Metal

Name: XC3000 Water Cooling Gantry Fiber Laser Cutting Machine New for Raytools for Grille Door Window Advertising for Sheet Metal
Brand: TOPLOONG
Price: 3 USD

Buy cheap XC3000 Water Cooling Gantry Fiber Laser Cutting Machine New for Raytools for Grille Door Window Advertising for Sheet Metal product

Place of Origin : Anhui, China

Brand Name : TOPLOONG

MOQ : 1 set

Price : $3,500-3,980 / set

Payment Terms : T/T,Western Union

Supply Ability : 100

Delivery Time : 5-8

Packaging Details : wood box

Applicable Material : Metal, steels

condition : New

laser type : Fiber Laser

Cutting Speed : 12m /min

graphic format supported : AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP

cutting thickness : 0.5-3mm

cnc or not : Yes

cooling mode : Water Cooling

laser head brand : Raytools

servo motor brand : Leadshine

guiderail brand : HIWIN

control system brand : Cypcut

Weight : 350

Key Selling Points : Competitive Price

optical lens brand : II-VI

warranty : 1 Year

mode of operation : continuous wave

configuration : 3-axis

products handled : Sheet Metal

Feature : SERVO-MOTOR

Product name : Fiber Laser Metal Cutting Machine

Keyword : Laser Metal Cutting Cnc Machine

Function : Fiber Laser Cutting Metal

Laser power : 1000W /1500W/ 2000W / 3000W

Cutting materials : Stainless Steel Carbon Steel Aluminum

After-sales Service Provided : Video Technical Support

Laser head : Raytools Cutting Head

Laser source : MXA RECI

Color : Blue-white-Black-lemon

Optional : Spliced table

Contact Now

Product Overview

3015 CNC FIBER LASER CUTTING MACHINE

FEATURES AT A GLANCE

COMPACT DIMENSIONS

EXTENDING UNDERCARRIAGE

SAFETY FRAME

SIMPLE CONTROL

SEASY MAINTENANCE

VERSATILITY

EXTENDING UNDERCARRIAGE

XC3000 Water Cooling Gantry Fiber Laser Cutting Machine New for Raytools for Grille Door Window Advertising for Sheet Metal

PRODUCT SPECIFICATIONS

No	Item	Data
1	Power	1.5 2 3KW
2	Capacity	0.3-30mm
3	Operating system	RAYTOOLS PC
4	X rail effective	1500mm
5	Y rail effective	3000mm
6	Motor type	Servo motor drive
7	Laser source	MAX RECI
8	Rack gears	Helical

PRODUCT CONFIGURATION

water chiller

Racks gear

servo motor

SALES AND SERVICE NETWORK

Successful Project

Project in Thailand

Project in India

Project in Russia

SIMILAR PRODUCTS

FAQ

Cut thickenss Gas options 1200W(220v single phase): 1. >13bar air compressor (cut carbon steel 0.3-4mm , stainless steel,aluminum 0.3-4mm) 2. oxygen cylinder (cut carbon steel 0.3-12mm), 40L bottle can use 6.5hrs 3. Nitrogen cylinder(cut fine quality stainless steel , aluminum 0.3-4mm) Average power consumption 3-4KW Peak 6KW Cut thickenss Gas options 1500W(220v single phase): 1. >13bar air compressor (cut carbon steel 0.3-6mm , stainless steel,aluminum 0.3-6mm) 2. oxygen cylinder (cut carbon steel 0.3-16mm), 40L bottle can use 6.5hrs 3. Nitrogen cylinder(cut fine quality stainless steel , aluminum 0.3-6mm) Average power consumption 4.5-5KW Peak 7.5KW Cut thickenss Gas options 2000W(220v single phase): 1. >13bar air compressor (cut carbon steel 0.3-10mm , stainless steel,aluminum 0.3-8mm) 2. oxygen cylinder (cut carbon steel 0.3-20mm), 40L bottle can use 6.5hrs 3. Nitrogen cylinder (cut fine quality stainless steel , aluminum 0.3-8mm) Average power consumption 6-7KW Peak 9KW Cut thickenss Gas options 3000W(380v 3phase): 1. air compressor (cut carbon steel 0.3-12mm , stainless steel,aluminum 0.3-10mm) 2. oxygen cylinder (cut fine quality carbon steel 0.3-22mm), 40L bottle can use 6.5hrs 3. Nitrogen cylinder(cut fine quality stainless steel , aluminum 0.3-10mm) Average power consumption 9-10KW Peak 15KW Cut thickenss Gas options 6000W(380v 3phase): 1. air compressor (cut carbon steel 0.3-18mm , stainless steel,aluminum 0.3-18mm) 2. oxygen cylinder (cut fine quality carbon steel 0.3-24mm), 40L bottle can use 6.5hrs 3. Nitrogen cylinder(cut fine quality stainless steel ,aluminum 0.3-20mm) Cut thickenss Gas options 12000W(380v 3phase): 1. air compressor (cut carbon steel 0.3-25mm , stainless steel,aluminum 0.3-30mm) 2. oxygen cylinder (cut fine quality carbon steel 0.3-40mm), 40L bottle can use 6.5hrs 3. Nitrogen cylinder(cut fine quality stainless steel ,aluminum 0.3-40mm)
